GitLab Runner Performance Optimization: From Slow Pipelines to Speed

Ever watched a simple lint check take 5 minutes when it should take 30 seconds? Or stared at a “Pending” pipeline wondering if your runner is even alive? Yeah, me too.

Here’s the thing - most GitLab Runner guides focus on getting it working, not making it fast. But if you’re self-hosting GitLab with a separate runner VM, there are hidden performance killers that nobody warns you about.

This is what we learned after debugging slow pipelines on our self-hosted GitLab setup. Real optimizations that cut our pipeline times by 60% without upgrading hardware.

⏱️ Reading time: 12-15 minutes

Why Pipelines Are Slow (It’s Not Your CPU)

When I first set up our GitLab Runner, pipelines were painfully slow. I checked htop on both the GitLab server and runner - barely any load. The VMs weren’t struggling, so what was going on?

After hours of debugging, here’s what I found:

• Network latency through Cloudflare - Runner was going through the public internet to reach GitLab
• No caching - Every job ran npm ci from scratch
• Suboptimal runner config - Default settings aren’t optimized for performance
• DNS resolution delays - Docker containers couldn’t resolve internal hostnames

Here’s what proper optimization fixes:

• Pipeline times drop 50-70% - Direct connections + caching = speed
• No more “Pending” jobs - Runner picks up work instantly
• Consistent build times - Cache hits mean predictable performance
• Lower resource usage - Less network traffic, fewer redundant operations

Our Infrastructure Setup

Before diving into optimizations, here’s what we’re working with:

Both VMs run on Proxmox in the same local network. External users access GitLab through Cloudflare Tunnel, which proxies gitlab.example.com to the internal server.

flowchart LR
  subgraph Internet
      DEV[Developer Laptop]
      CF[Cloudflare]
  end

  subgraph "Local Network (192.168.1.x)"
      GS[GitLab Server<br/>192.168.1.10]
      GR[GitLab Runner<br/>192.168.1.11]
  end

  DEV -->|HTTPS| CF
  CF -->|Tunnel| GS
  GR -.->|"❌ Slow: via Cloudflare"| CF
  GR -->|"✅ Fast: Direct HTTP"| GS

  style CF fill:#f5a623,stroke:#333
  style GS fill:#7b42bc,stroke:#333,color:#fff
  style GR fill:#2496ed,stroke:#333,color:#fff

The problem: By default, the runner was connecting to gitlab.example.com which resolved to Cloudflare IPs, sending all traffic through the internet and back - even though both VMs are on the same network!

Optimization 1: Direct Internal Connection

This is the single biggest performance improvement. Make the runner talk directly to GitLab over the local network.

The Problem

Check your runner logs:

sudo journalctl -u gitlab-runner -n 20 --no-pager

If you see errors like this, your runner is going through Cloudflare:

dial tcp 104.21.9.142:443: i/o timeout

Those IPs (104.21.x.x, 172.67.x.x) are Cloudflare, not your GitLab server.

The Fix

Step 1: Find what port GitLab is listening on

On your GitLab server:

ss -tlun | grep -E '80|443|5443'

Typical output:

tcp   LISTEN 0      511    0.0.0.0:80    0.0.0.0:*

This shows GitLab is listening on port 80 (HTTP) internally.

Step 2: Update runner config.toml

On the runner VM, edit /etc/gitlab-runner/config.toml:

[[runners]]
  name = "gitlab-runner-01"
  url = "http://192.168.1.10/"
  clone_url = "http://192.168.1.10/"
  # ... rest of config

Key changes:

• url - Use internal IP with HTTP (not HTTPS)
• clone_url - Ensures git operations also use internal network

Step 3: Configure Docker containers to resolve hostnames

Jobs run inside Docker containers that also need to reach GitLab. Add extra_hosts:

[runners.docker]
  extra_hosts = ["gitlab.example.com:192.168.1.10", "registry.example.com:192.168.1.10"]

This adds entries to /etc/hosts inside every container, so gitlab.example.com resolves to your internal IP.

Step 4: Restart the runner

sudo gitlab-runner restart
sudo journalctl -u gitlab-runner -f

You should now see successful job checks without timeout errors.

Before vs After

Optimization 2: Runner Resource Configuration

Default runner settings are conservative. Let’s tune them for performance.

Recommended config.toml

concurrent = 2
check_interval = 3
connection_max_age = "15m0s"
shutdown_timeout = 0

[session_server]
  session_timeout = 1800

[[runners]]
  name = "gitlab-runner-01"
  url = "http://192.168.1.10/"
  clone_url = "http://192.168.1.10/"
  executor = "docker"
  request_concurrency = 2

  [runners.cache]
    MaxUploadedArchiveSize = 0

  [runners.docker]
    tls_verify = false
    image = "alpine:latest"
    privileged = true
    disable_entrypoint_overwrite = false
    oom_kill_disable = false
    disable_cache = false
    volumes = ["/cache"]
    shm_size = 536870912
    network_mtu = 0
    cpus = "1.5"
    memory = "2560m"
    pull_policy = ["if-not-present"]
    extra_hosts = ["gitlab.example.com:192.168.1.10", "registry.example.com:192.168.1.10"]

Key Settings Explained

Memory Budget Calculation

For a runner with 8GB RAM:

System/Docker overhead:  ~1.5GB
Runner process:          ~0.5GB
Container 1:              2.5GB
Container 2:              2.5GB
Buffer:                   1.0GB
─────────────────────────────────
Total:                    8.0GB ✓

Optimization 3: Pipeline Caching Strategy

Running npm ci on every job wastes 30-60 seconds. Let’s fix that.

The Problem

Without caching, every job in your pipeline:

1. Downloads packages from npm registry
2. Installs all dependencies from scratch
3. Repeats this even though package-lock.json hasn’t changed

The Solution: Dedicated Install Stage

image: node:24.12.0-trixie-slim

stages:
  - install
  - lint
  - build
  - test
  - deploy

variables:
  NPM_CONFIG_CACHE: .npm
  npm_config_prefer_offline: 'true'
  npm_config_audit: 'false'
  npm_config_fund: 'false'

# Global cache - all jobs can pull from this
cache:
  key:
    files:
      - package-lock.json
  paths:
    - .npm/
    - node_modules/
  policy: pull # Most jobs only read cache

# ===============================
# STAGE: INSTALL
# ===============================
install_deps:
  stage: install
  cache:
    key:
      files:
        - package-lock.json
    paths:
      - .npm/
      - node_modules/
    policy: pull-push # This job updates the cache
  script:
    - npm ci
  rules:
    - if: $CI_PIPELINE_SOURCE == "merge_request_event"
    - if: $CI_COMMIT_BRANCH

How Other Jobs Use the Cache

lint_code:
  stage: lint
  needs:
    - job: install_deps
      optional: true
  script:
    - '[ -d node_modules ] || npm ci' # Fallback if cache miss
    - npm run lint
    - npm run format:check
  rules:
    - if: $CI_PIPELINE_SOURCE == "merge_request_event"
    - if: $CI_COMMIT_BRANCH =~ /^(develop|main)$/

build_site:
  stage: build
  needs:
    - job: install_deps
      optional: true
  script:
    - '[ -d node_modules ] || npm ci'
    - npm run build
  artifacts:
    paths:
      - dist/
    expire_in: 1 day
  rules:
    - if: $CI_COMMIT_BRANCH

Cache Key Strategy

The cache key is based on package-lock.json:

cache:
  key:
    files:
      - package-lock.json

This means:

• Same package-lock.json = cache hit = fast
• Changed package-lock.json = cache miss = full install (expected)

Cache Hit vs Miss Performance

Optimization 4: Use needs for Parallel Execution

By default, GitLab runs stages sequentially. The needs keyword enables parallel execution.

Without needs (Sequential)

install → lint → build → test → deploy
  30s      40s     60s    20s     30s   = 180s total

With needs (Parallel)

lint_code:
  needs:
    - job: install_deps
      optional: true # Don't fail if install_deps was skipped

build_site:
  needs:
    - job: install_deps
      optional: true

test_build:
  needs:
    - job: build_site
      artifacts: true # Download artifacts from build_site

install ──→ lint ──────────→ deploy
   30s  ╲     40s              30s
         ╲
          → build → test ──→
             60s     20s

Jobs that don’t depend on each other run in parallel, reducing total pipeline time.

Optimization 5: Sync Develop After Production Deploy

This prevents the “source branch is X commits behind target” error in future merge requests.

# ===============================
# STAGE: POST-DEPLOY
# ===============================
# Add GITLAB_INTERNAL_IP as a CI/CD variable (e.g., 192.168.1.10)
sync_develop:
  stage: post-deploy
  image: alpine:latest
  variables:
    GIT_STRATEGY: clone
    GIT_DEPTH: 0
  before_script:
    - apk add --no-cache git
    - git config user.email "[email protected]"
    - git config user.name "GitLab CI"
    - git remote set-url origin "http://oauth2:${PUSH_TOKEN}@${GITLAB_INTERNAL_IP}/${CI_PROJECT_PATH}.git"
  script:
    - git fetch origin develop
    - git checkout develop
    - git merge origin/main --no-edit
    - git push origin develop
  rules:
    - if: $CI_COMMIT_BRANCH == "main" && $CI_PIPELINE_SOURCE == "push"
  allow_failure: true

Why Use Internal IP in sync_develop?

Notice we use http://oauth2:${PUSH_TOKEN}@${GITLAB_INTERNAL_IP}/ instead of ${CI_SERVER_HOST}.

That’s because:

• CI_SERVER_HOST = gitlab.example.com (external URL)
• CI_SERVER_PORT = 443 (Cloudflare HTTPS)
• Inside Docker container, this routes through Cloudflare = slow + may fail

Using the internal IP keeps git operations on the local network.

Complete Optimized .gitlab-ci.yml

Here’s a complete example putting it all together:

image: node:24.12.0-trixie-slim

stages:
  - install
  - lint
  - build
  - test
  - deploy
  - post-deploy

default:
  interruptible: true

variables:
  NPM_CONFIG_CACHE: .npm
  npm_config_prefer_offline: 'true'
  npm_config_audit: 'false'
  npm_config_fund: 'false'

cache:
  key:
    files:
      - package-lock.json
  paths:
    - .npm/
    - node_modules/
  policy: pull

# ===============================
# STAGE: INSTALL
# ===============================
install_deps:
  stage: install
  cache:
    key:
      files:
        - package-lock.json
    paths:
      - .npm/
      - node_modules/
    policy: pull-push
  script:
    - npm ci
  rules:
    - if: $CI_PIPELINE_SOURCE == "merge_request_event"
    - if: $CI_COMMIT_BRANCH

# ===============================
# STAGE: LINT
# ===============================
lint_code:
  stage: lint
  needs:
    - job: install_deps
      optional: true
  script:
    - '[ -d node_modules ] || npm ci'
    - npm run lint
    - npm run format:check
  rules:
    - if: $CI_PIPELINE_SOURCE == "merge_request_event"
    - if: $CI_COMMIT_BRANCH =~ /^(develop|main)$/

lint_commit:
  stage: lint
  needs:
    - job: install_deps
      optional: true
  variables:
    GIT_DEPTH: 0
  script:
    - '[ -d node_modules ] || npm ci'
    - npx commitlint --from $CI_MERGE_REQUEST_DIFF_BASE_SHA --to $CI_MERGE_REQUEST_DIFF_HEAD_SHA
  rules:
    - if: $CI_PIPELINE_SOURCE == "merge_request_event"

# ===============================
# STAGE: BUILD
# ===============================
build_site:
  stage: build
  needs:
    - job: install_deps
      optional: true
  script:
    - '[ -d node_modules ] || npm ci'
    - npm run build
  artifacts:
    paths:
      - dist/
    expire_in: 1 day
  rules:
    - if: $CI_COMMIT_BRANCH

# ===============================
# STAGE: TEST
# ===============================
test_build:
  stage: test
  needs:
    - job: build_site
      artifacts: true
  script:
    - test -d dist
    - test "$(ls -A dist)"
  rules:
    - if: $CI_COMMIT_BRANCH

# ===============================
# STAGE: DEPLOY
# ===============================
deploy_develop:
  stage: deploy
  needs:
    - job: build_site
      artifacts: true
  variables:
    NODE_ENV: production
  before_script:
    - npm install -g wrangler
  script:
    - wrangler pages deploy dist --project-name=my-project --branch=develop
  environment:
    name: develop
    url: https://develop.my-project.pages.dev
  rules:
    - if: $CI_COMMIT_BRANCH == "develop"

deploy_production:
  stage: deploy
  needs:
    - job: build_site
      artifacts: true
  variables:
    NODE_ENV: production
  before_script:
    - npm install -g wrangler
  script:
    - wrangler pages deploy dist --project-name=my-project --branch=main
  environment:
    name: production
    url: https://my-project.example.com
  rules:
    - if: $CI_COMMIT_BRANCH == "main"

# ===============================
# STAGE: POST-DEPLOY
# ===============================
sync_develop:
  stage: post-deploy
  image: alpine:latest
  variables:
    GIT_STRATEGY: clone
    GIT_DEPTH: 0
  before_script:
    - apk add --no-cache git
    - git config user.email "[email protected]"
    - git config user.name "GitLab CI"
    - git remote set-url origin "http://oauth2:${PUSH_TOKEN}@${GITLAB_INTERNAL_IP}/${CI_PROJECT_PATH}.git"
  script:
    - git fetch origin develop
    - git checkout develop
    - git merge origin/main --no-edit
    - git push origin develop
  rules:
    - if: $CI_COMMIT_BRANCH == "main" && $CI_PIPELINE_SOURCE == "push"
  allow_failure: true

Troubleshooting Common Issues

Issue 1: Pipeline Stuck in “Pending”

Symptoms: Jobs show “Pending” indefinitely, runner appears online.

Check runner logs:

sudo journalctl -u gitlab-runner -f

Common causes:

1. Runner URL mismatch - config.toml URL doesn’t match GitLab’s expected URL
2. Network timeout - Runner can’t reach GitLab
3. Tag mismatch - Jobs require tags the runner doesn’t have

Fix: Verify url in config.toml matches what GitLab expects:

sudo gitlab-runner verify

Issue 2: “connection refused” Errors

dial tcp 192.168.1.10:443: connect: connection refused

Cause: Wrong port. GitLab is on port 80 (HTTP), not 443 (HTTPS).

Fix: Use HTTP URL without port:

url = "http://192.168.1.10/"

Issue 3: “unauthorized” in Container Jobs

fatal: unable to access 'https://gitlab.example.com/...':
Failed to connect to gitlab.example.com port 443

Cause: Container can’t resolve hostname or wrong port.

Fix: Use internal IP directly in job scripts:

git remote set-url origin "http://oauth2:${TOKEN}@${GITLAB_INTERNAL_IP}/${CI_PROJECT_PATH}.git"

Issue 4: Cache Never Hits

Symptoms: npm ci runs every time, “No cache found” in logs.

Common causes:

1. Cache key changed (check package-lock.json)
2. Cache expired (default 2 weeks)
3. Different runner picked up the job

Check cache status:

# In job log, look for:
Checking cache for <key>...
Successfully extracted cache
# or
No URL provided, cache will not be downloaded

Performance Checklist

Use this checklist to verify your setup:

• Runner connects to internal IP (e.g., http://192.168.1.10/)
• clone_url is set to internal URL
• extra_hosts configured for Docker containers
• pull_policy set to if-not-present
• request_concurrency set to 2+
• npm cache includes both .npm/ and node_modules/
• install_deps job uses policy: pull-push
• Other jobs use policy: pull
• needs configured for parallel execution
• interruptible: true set in defaults

The Bottom Line

Self-hosted GitLab is powerful, but default configurations prioritize compatibility over speed. The biggest wins come from:

1. Direct internal connections - Bypass Cloudflare for runner ↔ GitLab traffic
2. Aggressive caching - Cache node_modules, not just .npm
3. Parallel execution - Use needs to run independent jobs simultaneously
4. Proper resource allocation - Tune concurrent, cpus, and memory

Our pipeline went from 5-8 minutes to under 2 minutes with these changes. Your mileage may vary, but expect 50-70% improvement on most setups.

Start with the internal connection fix - it’s the lowest effort, highest impact change you can make.

Next Steps: Implement This Today

Additional Resources

• GitLab Runner Advanced Configuration
• GitLab CI/CD Caching
• GitLab CI/CD Job Artifacts
• needs Keyword Documentation

Share this post

Found this helpful? Share it with your network!

• Share on Facebook, opens in a new tab
• Share on Twitter, opens in a new tab
• Share on LinkedIn, opens in a new tab
